Hunter X-CORE

I-25 Ultra Performance Charts
I-25 Ultra Nozzle
Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
4
Yellow
40
50
60
70
40'
41'
42'
43'
3.8
4.3
4.7
5.1
0.46
0.49
0.51
0.53
0.53
0.57
0.59
0.61
5
White
40
50
60
70
43'
44'
45'
46'
4.4
4.8
5.3
5.6
0.46
0.48
0.50
0.51
0.53
0.55
0.58
0.59
7
Orange*
40
50
60
70
45'
47'
48'
49'
6.6
7.0
7.5
7.9
0.63
0.61
0.63
0.63
0.72
0.70
0.72
0.73
8
Lt.
Brown
40
50
60
70
47'
49'
50'
51'
7.7
8.3
9.2
9.9
0.67
0.67
0.71
0.73
0.77
0.77
0.82
0.85
10
Lt.
Green*
50
60
70
80
51'
52'
53'
54'
10.1
11.1
12.1
12.9
0.75
0.79
0.83
0.85
0.86
0.91
0.96
0.98
13
Lt.
Blue
50
60
70
80
53'
54'
55'
55'
11.2
12.3
13.3
14.3
0.77
0.81
0.85
0.91
0.89
0.94
0.98
1.05
15
Gray*
50
60
70
80
56'
57'
57'
58'
13.4
14.3
15.2
16.4
0.82
0.85
0.90
0.94
0.95
0.98
1.04
1.08
18
Red
50
60
70
80
58'
59'
62'
63'
14.5
15.7
16.9
18.2
0.83
0.87
0.85
0.88
0.96
1.00
0.98
1.02
20
Dk.
Brown*
60
70
80
90
62'
63'
64'
65'
17.8
19.2
20.5
21.8
0.89
0.93
0.96
0.99
1.03
1.08
1.11
1.15
23
Dk.
Green
60
70
80
90
64'
65'
66'
67'
21.9
23.6
25.6
27.0
1.03
1.08
1.13
1.16
1.19
1.24
1.31
1.34
25
Dk.
Blue*
60
70
80
90
66'
68'
69'
70'
23.5
25.5
28.0
29.5
1.04
1.06
1.13
1.16
1.20
1.23
1.31
1.34
28
Black
70
80
90
100
68'
70'
71'
71'
26.9
28.7
30.6
31.5
1.12
1.13
1.17
1.20
1.29
1.30
1.35
1.39
I-25 Ultra High-Speed Nozzle
Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
4
Yellow
40
50
60
70
37'
38'
38'
39'
3.8
4.3
4.7
5.2
0.53
0.57
0.63
0.66
0.62
0.66
0.72
0.76
5
White
40
50
60
70
38'
39'
40'
41'
4.4
4.8
5.5
6.0
0.59
0.61
0.66
0.69
0.68
0.70
0.76
0.79
7
Orange*
40
50
60
70
40'
41'
42'
44'
6.1
6.9
7.5
8.1
0.73
0.79
0.82
0.81
0.85
0.91
0.95
0.93
8
Lt.
Brown
40
50
60
70
42'
43'
44'
45'
7.2
8.1
8.9
9.8
0.79
0.84
0.88
0.93
0.91
0.97
1.02
1.08
10
Lt.
Green*
50
60
70
80
46'
48'
49'
50'
10.1
11.1
12.1
12.9
0.92
0.93
0.97
0.99
1.06
1.07
1.12
1.15
13
Lt.
Blue
50
60
70
80
48'
49'
51'
51'
11.2
12.3
13.3
14.3
0.94
0.99
0.98
1.06
1.08
1.14
1.14
1.22
15
Gray*
50
60
70
80
49'
51'
53'
54'
13.4
14.3
15.2
16.4
1.07
1.06
1.04
1.08
1.24
1.22
1.20
1.25
18
Red
50
60
70
80
50'
53'
55'
57'
14.5
15.7
16.9
18.2
1.12
1.08
1.08
1.08
1.29
1.24
1.24
1.25
20
Dk.
Brown*
60
70
80
90
53'
56'
58'
59'
17.8
19.2
20.5
21.8
1.22
1.18
1.17
1.21
1.41
1.36
1.35
1.39
23
Dk.
Green
60
70
80
90
56'
58'
60'
61'
21.9
23.6
25.6
27.0
1.34
1.35
1.37
1.40
1.55
1.56
1.58
1.61
25
Dk.
Blue*
60
70
80
90
58'
62'
64'
66'
23.5
25.5
28.0
29.5
1.34
1.28
1.32
1.30
1.55
1.47
1.52
1.51
28
Black
70
80
90
100
60'
62'
65'
67'
26.9
28.7
30.6
31.5
1.44
1.44
1.39
1.35
1.66
1.66
1.61
1.56
* 5 standard nozzles included with each sprinkler.
Note: All preciptation rates calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler,
divide by 2.
