48 – English
Dismantling
1. Remove the cutting deck, see “Remove the
cutting deck” on page 57.
2. Raise and support the product.
3. Remove the front wheels.
4. Release the front synchronisation link for speed
from the front transmission.
5. Drain the oil. See “5.2.3 Transmission oil change”
on page 28.
6. Release the hydraulic pipes from underside the
transmission. Attach the protective plugs.
7. Remove the left front wing.
8. Release the hydraulic pipe from the top on the
transmission. Attach the protective plug.
9. Release the partking brake cable.
Hydraulic system
