Hussmann Super Plus - Main Liquid Line Pressure Differential Valve; 3-Way Valve

Revised August 1, 1996 P/N 340272A
2 - 3
Ball Valve
Check Valve
Compressor Service Valve
2-Way Valve
3-Way Valve
Valve Solenoids
Sight Glass
Suction Filter
Liquid Line Drier
Thermal Expansion Valve
(TEV)
Pressure Regulating Valve
A8 for Condenser
A9 for Receiver
EPR for Evaporator
Main Liquid Line Pressure
Differential Valve
Autosurge Valve (Optional)
Heat Exchanger (Optional)
High Pressure Hot Vapor
High Pressure Warm Vapor
High Pressure Warm Liquid
Reduced Pressure Wa r m
Liquid
Low Pressure Cool Vapor
Cut-away not shown
(Empty)
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 • Printed in USA
