The Flooding Charges listed in the table
above reflect additional refrigerant required
for split condenser method of winter control
above normal summer operating charge and
heat reclaim coil requirements.
N o t e : Condenser ambient should be noted
when determining the flooding charge.
• If above 65˚F, add the specified amounts
of refrigerant when the system stabi-
lizes after start-up.
• If below 65˚F but above the coldest
expected, some condenser flooding
will already be occurring and required
additional charge will be lower.
• If the coldest expected temperature is
above 20˚F, the flooding charg e
required will be less than 50% of each
condenser circuit.
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 • Printed in USA
Revised August 1, 1996 P/N 340272A
5 - 3
Physical Data
Weight /w Max Flood Inlet/Outlet
No. FLA 3PH Max. Flood Charge Connections
Model Fans (lbs) (lbs) OD
R404A/ R404A/
208V 230V 460V R22 R507 R22 R507
1x1 2.8 2.6 1.3 205 221 19 35 1 1/8
HLCVB 1x2 5.6 5.2 2.6 410 445 40 75 1 3/8*
1x3 8.4 7.8 3.9 615 666 59 110 1 3/8
1x4 11.2 10.4 5.2 925 1002 88 165 1 5/8
1x5 14.0 13.0 6.5 1039 1125 99 185 2 1/8
1x6 16.8 15.6 7.8 1239 1343 119 223 2 1/8
1x7 19.6 18.2 9.1 1551 1679 147 275 2 5/8
1x2 8.8 8.0 4.0 1081 1137 64 120 1 5/8
HLCVF 1x3 13.2 12.0 6.0 1574 1658 96 180 2 1/8
1x4 17.6 16.0 8.0 2240 2352 128 240 1 5/8
HLCVG 1x5 22.0 20.0 10.0 3020 3231 242 453 2 5/8
1x6 26.4 24.0 12.0 3555 3809 291 545 2 5/8
2x2 11.2 10.4 5.2 820 897 88 165 1 3/8*
HLCVI 2x3 16.8 15.6 7.8 1230 1334 119 223 1 3/8
2x4 22.4 20.8 10.4 1850 2003 176 329 1 5/8
2x5 28.0 26.0 13.0 2078 2263 212 397 2 1/8
2x6 33.6 31.2 15.6 2420 2627 237 444 2 1/8
2x7 39.2 36.4 18.2 3075 3332 295 552 2 5/8
2x2 17.6 16.0 8.0 2001 2113 128 240 1 5/8
HLCVV 2x3 26.4 24.0 12.0 2889 3055 191 357 2 1/8
2x4 35.2 32.0 16.0 3733 3955 255 477 2 1/8
HLCVW 2x5 44.0 40.0 20.0 5020 5433 474 887 2 5/8
2x6 52.8 48.0 24.0 6030 6527 570 1067 2 5/8
*Inlet = 1 3/8, Outlet = 1 1/8
O
N
E
F
A
N
W
I
D
E
T
W
O
F
A
N
S
W
I
D
E
