HydraMaster CDS 4.8 - Page 104

Assemblies and Parts Lists: 7-56
Table 7-3. Hose Routings
Part Number Description From To
000-068-092 Hose, 3/8” X 15” Teon w/ 3/8” JIC End Dual Heat Exchanger By-Pass Valve
000-068-1037 Hose, 3/8” I.D. X 39” Lg., Clr w/Braid Chemical Jug Chemical Meter
000-068-1039 Hose, 3/8” I.D. Rubber X 31” Lg. By-Pass Valve Recovery Tank
000-068-196 Hose, 3/8” I.D. X 11” Lg w/ 3/8” MPT and 3/8” JIC End By-Pass Valve Dual Heat Exchanger
000-068-203 Hose, 3/16” X 34” Teon 1/4” F JIC X 1/4” F JIC Water Box Hi-PSI Manifold
000-068-385 Hose, 3/4” I.D. X 18 ft - Green Stripe - Cut to Fit Dual Heat Exchanger Van Cooling System
000-068-734 Hose, 1/2” X 42.5 Lg w/ 3/8” NPT and 3/8” SAE F Ends Water Box Water Outlet
000-068-940 Hose, 3/8” I.D. Rubber X 17” Lg. Hi-PSI Manifold Dual Heat Exchanger
000-068-977 Hose, 5/32” I.D. Vacuum X 52” Lg. Pressure Gauge Blower Outlet
000-068-978 Hose, 5/32” I.D. Vacuum X 82” Lg. Lube Port Blower
000-068-991 Hose, 1/2” I.D. Rubber X 42” Lg. Water Box By-Pass Valve
