Assemblies and Parts Lists: 7-14
Pump Assembly Parts List
1 000-001-154 Adapter, GP to Chemical Pump S/S 4.0 gallon 1
2 000-015-927 Bracket, Compressor Mount - Coated 1
3 000-052-062 Bushing, 1/4” NPT Male X 1/4” NPT Female 1
4 000-036-008 Clutch, 7” O.D. 24mm Single Groove 1
5 000-052-085 Elbow, 1/4” NPT Street 1
6 000-052-084 Elbow, 1/8” NPT Street 2
7 000-052-531 Elbow, 1/8” NPT X 1/4” SAE 1
8 000-052-086 Elbow, 3/8” NPT Street 1
9 000-052-099 Insert, #26 (1/8” NPT X 3/8” Barb) 1
Item Part Number Description Qty Item Part Number Description Qty
10 000-052-753 Insert, #816 (1/2” NPT X 1” Barb) 1
11 000-052-128 Nipple, 3/8 MPT X 3/8SAE Flare 1
12 000-094-071 Nut, 1/4”-20UNC Nylock 4
13 000-097-057 O-Ring, Adapter - Chemical Pump 1
14 000-105-550 Plate, Pump Clutch - GP 4.0 gpm 1
15 000-111-188 Pump, 4.0 gpm GP 1
16 000-111-184 Pump, GP Chemical 1
17 000-143-141 Screw, 1/4”-20UNC X 1/2” Lg. Whiz Lock 4
18 000-169-216 Valve, GP Pump Check - Mod. - 4.0 gallon 1
