5
29
2X
28
2X
21
2X
26
2X
30
23
2X
16
27
14
22
28
28
2X
20
2X
15 30 26
HIDDEN
3
1
2
12
10
11
9
13
PUMP TO
BYPASS VALE
PUMP TO
HI PSI MANIFOLD
CHEMICAL PUMP
TO CHEMICAL METER
PUMP TO
WATER BOX
000-108-216
PROTECTOR, 4.8 REAR BELTS - COATED
PART OF KIT 000-078-562
24
4X
30
4X
26
4X
4 17
25
2X
27
2X
19
2X
23
2X
30
26
2X
15 30 26
HIDDEN
18
6
8
7
7
8
13
10119
12
H
G
ITEM NO.
QTY.
DESCRIPTION
MATERIAL
PART NO.
30 8
WASHER, 5/16" LOCK
S. STEEL
000-174-018
29 2
WASHER, 5/16" FLAT, USS
STEEL
000-174-004
28 5
WASHER, 3/8" LOCK
STEEL
000-174-021
27 3
WASHER, 1/4" LOCK S/S
S. STEEL
000-174-019
26 10
WASHER, 1/4" FLAT
STEEL
000-174-002
25 2
WASHER, 1/4" FLAT
S. STEEL
000-174-003
24 4
SCREW, 5/16"-18UNC x 3/4" LG.
S. STEEL
000-143-012
23 4
SCREW, 5/16"-18UNC x 1.00" LG. HEX HEAD GRADE 8
STEEL
000-143-013
22 1
SCREW, 3/8"-16UNC X 2.50" LG. HEX HEAD
STEEL
000-143-098
21 2
SCREW, 3/8"-16UNC X 1.00" LG. HEX HEAD - GRADE 8
STEEL
000-143-018
20 2
SCREW, 3/8"-16UNC X 1.00" LG. HEX HEAD
S. STEEL
000-143-096
19 2
SCREW, 1/4"-20UNC x 0.50" LG. WHIZ LOCK
S. STEEL
000-143-141
18 1
PULLEY, AK51H
STEEL
000-109-043
17 1
PROTECTOR, PUMP DRIVE BELT - COATED
ASTM A1008
CS TYPE B
000-108-109
16 1
PROTECTOR, PUMP BELT SHIELD - COATED
A 1008 CS
TYPE B
000-108-065
15 2
NUT, 5/16"-18UNC HEX
STEEL
000-094-012
14 1
NUT, 1/4"-20UNC HEX S/S
S. STEEL
000-094-010
13 1
HOSE,CDS BLOWER OIL DRAIN
VARIOUS
000-068-149
12 1
HOSE, 3/8" X 52" LG. THROB - CDS
VARIOUS
000-068-588
11 1
HOSE, 3/8" I.D. HIGH TEMP X 72" LG.
RUBBER
000-068-1038
10 1
HOSE, 3/16" X 70" LG. TEFLON w/ FEM JIC ENDS
VARIOUS
000-068-706
9 1
HOSE, 1" X 65" LG. SUCTION
RUBBER
000-068-777
8 2
CLAMP, 1-1/2" T-BOLT
S. STEEL
000-033-132
7 2
CLAMP, SIZE #5 HOSE
AISI 304
000-033-005
6 1
BUSHING, #H x 7/8" BORE
STEEL
000-020-019
5 1
BELT, POLYCHAIN GT
VARIOUS
000-010-052
4 1
BELT, #9345 PUMP DRIVE
VARIOUS
000-010-065
3 1
ASSEMBLY, UNIVERSAL CDS FRAME
VARIOUS
601-001-701
2 1
ASSEMBLY, PUMP
VARIOUS
601-007-701
1 1
ASSEMBLY, BLOWER
VARIOUS
601-002-701
LTR
REVISION DESCRIPTION
CODE
DATE
BY
CHKD
APPVD
G
ADDED 108-216;
ECR #2810
12/7/2017
L.O.L.
M.B.B. M.B.B.
H
MOVE 108-216 TO 078-562 KIT.
ECR #2810
12/12/2017
L.O.L.
P.E.
ECRB
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
MACHINE
FINISH
125
SCALE: 1:3
SHEET 1 OF 1
PROPRIETARY INFORMATION
11015 47th Avenue West,
Mukilteo, Washington 98275
D
SIZE
BREAK ALL SHARP EDGES 0.005-.015
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
PART NUMBER
WEIGHT:
APPLICATION
NEXT ASSY
USED ON
601-004-701
REV
ASSEMBLY, POWERPACK
H
CDS 4.8
700-014-701-04
700-014-701-05
CDS 4.8
CDS 4.8
700-014-701-16
700-014-701-10
CDS 4.8
700-014-701-07
CDS 4.8
M.B.B.
M.B.B.
R.D.R.
DRAWN
CHECKED
APPVD
11/01/2011
12/07/2017
12/12/2017
TOLERANCES
.X=
.1
.XX=
.03
.XXX=
.010
ANGULAR =
2°
CODE:
241.04
