7-41: Assemblies and Parts Lists
Dura-Flow Automatic Pump Out (APO) Assembly Parts List- Production
1 000-111-169 ASSEMBLY, APO PUMP - JABSCO 1
2 000-015-908 BRACKET, DURAFLOW SUPPORT - FABRICATED 1
3 000-027-014 CAP, GARDEN HOSE 1
4 000-033-029 CLAMP, SIZE #12 HOSE 2
5 000-033-020 CLAMP, SIZE #16 HOSE 2
6 000-037-029 CONNECTOR, BUTT 10/12 1
7 000-037-003 CONNECTOR, BUTT 14/16 BLUE 3
8 000-052-131 ELBOW, 1” NPT x 1” BARB (GLASS FILLED BLACK
NYLON) 1
9 000-057-055 GASKET, GARDEN HOSE 1
10 000-063-021 HARNESS, 1/4 SPLIT WIRE LOOM 2’
11 000-068-1028 HOSE, 1” I.D. RUBBER X 16” LG. - RED 1
12 000-068-1027 HOSE, 3/4” I.D. EPDM X 36” LG. 1
13 000-052-758 INSERT, 1” NPT x 1” BARB 1
14 000-052-757 INSERT, 1” NPT x 3/4” ELBOW 1
15 000-052-338 INSERT, #1212 (3/4” NPT x 3/4” BARB) 1
Item Part Number Description Qty Item Part Number Description Qty
16 000-091-042 MOTOR, LEESON PE350 SERIES 1
17 000-052-281 NIPPLE, 3/4” NPT x 3/4” MALE GARDEN HOSE 1
18 000-143-074 SCREW, 1/4”-20UNC x 0.50” LG. HEX
HEAD SELF-TAPPING 4
19 000-143-001 SCREW, 1/4”-20UNC x 0.75” LG. HEX HEAD 2
20 000-143-566 SCREW, 1/4”-28UNF x 0.75” LG. SOCKET HEAD 4
21 000-157-091 SWITCH, HARWIL FLOAT - MODIFIED 1
22 000-037-017 TERMINAL, 3/8 STUD, 10GA WIRE, INSULATED 1
23 000-037-022 TERMINAL, 10 AWG FULLY INSULATED FE 1
24 000-037-023 TERMINAL, 10 AWG FULLY INSULATED MA 1
25 000-162-001 TIE WRAP, 4” NYLON 6
26 000-169-009 VALVE, 3/4” FPT SWING CHECK 1
27 000-174-050 WASHER, 1” FLAT 1
28 000-174-017 WASHER, 1/4” LOCK 2
29 000-174-002 WASHER, 1/4” FLAT 6
30 000-174-063 WASHER, 1.5” O.D. x 1.073” I.D. x 0.075” THK. 1
