7-39: Assemblies and Parts Lists
Figure 7-26. Float Valve Assembly
000-169-235 Rev. B
1 000-005-013 Float, 4” X 5” Poly 1
2 000-052-104 Insert, #66 (3/8” NPT X 3/8” Barb) 1
3 000-117-031 Rod, 4.5” Valve Stem 1
4 000-169-237 Valve, Body Inlet 1
Float Valve Assembly Parts List
Item Part Number Description Qty
1
3
4 2
