9-1: Electrical System
9 - Electrical System
Because the most dicult problem to trace in any system is often an electrical failure,
HydraMaster has designed the CDS’ electrical system with the technician in mind.
This section of the manual includes CDS troubleshooting guides as well as wiring
schematics and diagrams.
The entire electrical system operates on 12V DC which is provided by the vehicle’s battery.
To avoid equipment damage, it is very important to tie up any loose wires or hoses
near the drive shaft area. Tie wraps are sucient for wires and small hoses.
When securing large hoses or wiring harnesses in the area of the drive shaft, tie
down the components with a hose clamp, with a clear vinyl hose inserted onto the
clamp. On some installations, if the fuel injector wires are not properly secured,
the wires could rub against the CDS drive shaft causing a short in the electrical
system of the van.
