2 6 7
4
12
5
8
11
10
1
1
9
2
3
12 32
RIVET, 1/4" BLIND x 0.50" LG.
ALUMINUM
000-140-021
11 1
PROTECTOR, SALSA INSULATION SET
VARIOUS
000-108-140
10 1
PANEL, SALSA OUTLET - WELDMENT
ALUMINUM
000-100-155
9 1
PANEL, SALSA INLET - WELDMENT
ALUMINUM
000-100-154
8 1
NIPPLE, 3/8" NPT x 4" LG. BRASS
000-052-408
7 2
NIPPLE, 3/8" M JIC x 3/8" NPT
BRASS
000-052-528
6 1
HOSE, 3/8" X 31" LG. TEFLON w/ 3/8" JIC ENDS
VARIOUS
Copy of 000-068-755^000-
079-077
5 1
ELBOW, 3/8" NPT STREET
BRASS
000-052-086
4 1
ELBOW, 3/8" F x F BRASS
BRASS
000-052-142
3 1
ELBOW, 3.00" O.D. X 0.065 WALL 4.500" R w/ 2.00" TANGENTS
6061-T1
000-052-649
2 2
ELBOW, 3" RUBBER w/CLAMPS
VARIOUS
000-052-674
1 1
CORE, BLOWER HEAT EXCHANGER
VARIOUS
000-038-053
ITEM NO.
Default/QT
Y.
DESCRIPTION
MATERIAL
PART NO.
LTR
REVISION DESCRIPTION
CODE
DATE
BY
CHKD
APPVD
B
BROUGHT DRAWING TO MIT STANDARDS;
ASSIGNED NEW P/N; SKIPPED REV A.
MIT
1/18/2013
S.M.W.
C.I.R.
L.O.L.
C
REMOVED 000-068-801.
ECR #2587
2/11/2015
S.M.W.
C.I.R.
ECRB
D
C
B
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
A
KIT, CHEVY, SALSA 2005 CDS
C
REV
000-079-077
02/11/2015
03/19/09
03/19/09
USED ON
NEXT ASSY
APPLICATION
WEIGHT:
PART NUMBER
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
BREAK ALL SHARP EDGES 0.005-.015
SIZE
C
11015 47th Avenue West,
Mukilteo, Washington 98275
PROPRIETARY INFORMATION
SHEET 1 OF 1
SCALE: 1:8
APPVD
CHECKED
DRAWN
125
MACHINE
FINISH
KW
EJ
EJ
- - -
- - -
- - -- - -
- - -
- - -- - -
- - -- - -
- - - - - -
TOLERANCES
.X=
.1
.XX=
.03
.XXX=
.010
ANGULAR =
2°
CODE:
23.78
