HydraMaster CDS 4.8 - Figure 7-21. Recovery Tank Cover Assembly; Recovery Tank Cover Assembly Parts List

7-33: Assemblies and Parts Lists
Figure 7-21. Recovery Tank Cover Assembly
601-029-701 Rev. B
Recovery Tank Cover Assembly Parts List
1 000-052-219 Adapter, 2” NPT X 2” F Slip 2
2 000-041-447 Cover, 100 Gal. Universal Recovery Tank - Coated 1
3 000-052-222 Elbow, 2” Barb X 2” FPT 2
4 000-057-015 Gasket, 1-1/2” Bulkhead Fitting 2
5 000-057-202 Gasket, End - Rec. Tank Cover 2
6 000-057-203 Gasket, Middle - Rec. Tank Cover 3
7 000-057-205 Gasket, Side - Rec. Tank Cover 2
8 000-086-008 Latch, Bungee - Strike (Part of Tank Assembly) 1
9 000-094-063 Nut, #6-32UNC Nylock 2
10 000-143-539 Screw, #6-32UNC X 0.50” Lg. Button Head 2
11 000-078-039 Vacuum Inlet Stopper 1
Item Part Number Description Qty Item Part Number Description Qty
10
8
9
5
4
1
7
5
3
2
11
6
