HydraMaster CDS 4.8 - Instrument Panel Assembly Parts List

7-29: Assemblies and Parts Lists
Instrument Panel Assembly Parts List
1 601-009-701 Assembly, By-Pass Valve 1
2 601-008-701 Assembly, Hi-PSI Manifold 1
3 000-027-014 Cap, Garden Hose 1
4 000-033-023 Clamp, 3/4” Nylon Hose 3
5 000-033-005 Clamp, Size #5 Hose 4
6 000-052-272 Cup, Gravity Feed Oil Blower Lube Port 1
7 000-052-089 Elbow, 1/8” NPT Female 1
8 000-052-084 Elbow, 1/8” NPT Street 1
9 000-052-531 Elbow, 1/8” NPT X 1/4” SAE 1
10 000-052-088 Elbow, 1/4” FPT X FPT 1
11 000-052-589 Elbow, 3/4” NPT X 3/4” Barb 2
12 000-057-055 Gasket, Garden Hose 1
13 000-074-007 Gauge, Pressure 0 -1,500 psi 1
14 000-060-002 Grommet, Large Wiring 1
15 000-068-757 Hose, 1/2” X 20.5” Lg. Rubber w/ 3/8” NPT X 3/8” S 1
16 000-068-017 Hose, 3/8” Bulk 1
17 000-068-017 Hose, 3/8” Bulk 1
18 000-068-491 Hose, 3/16” X 10” Lg. Teon 1/4” NPT X 1/4” JIC F 1
19 000-068-518 Hose, 3/16” X 18.25” Lg. Teon w/F JIC Ends 1
20 000-052-099 Insert, #26 (1/8” NPT X 3/8” Barb) 3
21 000-052-104 Insert, #66 (3/8” NPT X 3/8” Barb) 1
22 000-052-338 Insert, #1212 (3/4” NPT X 3/4” Barb) 1
23 000-052-096 Insert, #F23 (1/8” FPT X 3/16” Barb) 1
24 000-081-376 Label, Lower Instrument Panel 1
25 000-081-375 Label, Upper Instrument Panel 1
26 000-074-030 Meter, Chemical Flow Raw 1
27 000-052-069 Nipple, 1/8” NPT Hex 2
28 000-052-530 Nipple, 1/4” SAE X 1/8” NPT 1
29 000-052-128 Nipple, 3/8” MPT X 3/8” SAE Flare 2
30 000-052-281 Nipple, 3/4” NPT X 3/4” Male Garden Hose 1
Item Part Number Description Qty
31 000-094-098 Nut, 7/16”-24UNF - 2 Way Metering Valve 1
32 000-094-004 Nut, #10-24UNC Hex 3
33 000-100-168 Panel, Instrument - Coated 1
34 000-105-012 Plate, Machine Serial I.D. 1
35 000-106-029 Plug, 1” Hole 1
36 000-052-051 Quick Connect, 440 Female w/ EPDM O-Ring 2
37 000-052-052 Quick Connect, 660 3/8” Brass w/ EPDM O-Ring 1
38 000-135-052 Regulator, Hi-PSI Snubber 1
39 000-140-015 Rivet, 1/8” X 1/4” Lg. Pop 2
40 000-143-166 Screw, #10-24UNC X 0.375” Lg. Hex Head 2
41 000-143-327 Screw, #10-32UNF X 0.50” Lg. Hex Head 2
42 000-143-134 Screw, #10-24UNC X 1” Lg. Hex Head S/S 4
43 000-052-022 Tee, 3/8” Insert 1
44 000-131-027 Trimlok, 1/8” X 3/16” Lg. 1
45 000-169-017 Valve, 3-Way Ball O-Ring Style 1
46 000-169-201 Valve, 3/4” Heater Panel Mount 1
47 000-169-064 Valve, 3/8” NPT Full Port Ball 1
48 000-169-009 Valve, 3/4” FPT Swing Check 1
49 000-169-160 Valve, Chemical Metering 1
50 000-174-050 Washer, 1” Flat 1
51 000-174-012 Washer, 1/2 SAE H/D 2
52 000-174-007 Washer, 1/2” Flat 1
53 000-174-063 Washer, 1.5” O.D. X 1.073” I.D. X 0.075” Thk. 1
54 000-174-005 Washer, 3/8” Flat 2
55 000-174-008 Washer, 5/8” Flat 4
56 000-174-030 Washer, 5/8” I.D. X 7/8” Od X 0.010” Thk 1
57 000-174-001 Washer, #10 Flat 10
58 000-174-014 Washer, #10 Lock 2
59 000-174-015 Washer, #10 Outside Star 3
Item Part Number Description Qty
