HydraMaster CDS 4.8 - Diffuser Filter Assembly Parts List; Figure 7-25. Diffuser Filter Assembly

Assemblies and Parts Lists: 7-38
Figure 7-25. Di󰀨user Filter Assembly
000-049-151 Rev. B
1 000-027-115 Cap, 2” PVC Modied for Di󰀨user 2
2 000-033-131 Clamp, Di󰀨user 1
3 000-052-104 Insert, #66 (3/8” NPT X 3/8” Barb) 1
Di󰀨user Filter Assembly Parts List
Item Part Number Description Qty
4
1
2
5
1 3
Item Part Number Description Qty
4 000-052-074 Nipple, 3/8” NPT Hex 1
5 000-125-222 Tube, Di󰀨user 1
