HydraMaster CDS 4.8 - CDS Front End Kit Assembly Parts List - Chevy (P;N 000-078-391)

7-19: Assemblies and Parts Lists
CDS Front End Kit Assembly Parts List - Chevy (P/N 000-078-391)
Part Number Description Qty Part Number Description Qty
000-008-011 BRG CDS CLUTCH FARM LINE 2
000-010-118 BELT 2003 CH 8 POLY 1
000-015-002 BRKT IDLER CAST CDS FRONT END 1
000-015-879 BRKT IDLER CASTING FR 2003 CH 1
000-015-880 BRKT 2003 CHEVY IDLERCASTING R 1
000-033-008 CLAMP SIZE 20 HOSE 2
000-033-029 CLAMP SIZE 12 HOSE 8
000-036-003 CLUTCH ASSY 6 CDS POLY GROOVE 1
000-052-716 TEE 1 3/8 X1 3/8 X3/4 UPPER CO 1
000-052-717 TEE 3/4 BARB X 3/4 BARB X3/4 B 1
000-077-008 KEY 5/32 X 3/4 WOODRUFF 1
000-077-009 KEY 3/16 X 3/4 WOODRUFF 1
000-094-009 NUT-1/4-20 S/S NYLOCK 4
000-094-010 NUT 1/4 20 S/S HEX 2
000-108-009 PROTECTOR FLYSTRAP TOP CLAMP C 1
000-108-127 PROTECTOR FLY STRAP COATED GMC 1
000-109-095 PULLEY 76MM CDS IDLER WITH DOU 1
000-139-005 RING CDS CLUTCH SHAFT 2
000-143-078 SCR 10MM X 30MM X 15 HHC 1
000-143-079 SCR 1/4 20 X 1/2 SS SOCHDCAP 1
000-143-126 SCREW 10-24 X .50 HHC S/S 2
000-143-558 SCR 10MM X 15 X 90MM HHCS GR 8 1
000-143-562 SCR 5/16 18 X 3/4 FLATHEAD CAP 4
000-143-563 SCR M 10 X 15 X 90MM SOCKET HE 1
000-143-564 SCR M 10 15 X 80MM HEX HEAD CA 2
000-150-009 SHAFT ELECTRIC CLUTCH CDS 1
000-150-174 DRIVESHAFT UNVRSL 39-44 2014- 1
000-154-141 SPACER CDS IDLER CASTING ALTER 2
000-174-003 WASHER - 1/4 ID FLAT S/S 4
000-174-104 WSHR CHEVY CDS IDLER CASTING 1
