HydraMaster CDS 4.8 - Water Box Assembly Parts List

7-37: Assemblies and Parts Lists
Water Box Assembly Parts List
1 000-049-151 ASSEMBLY, DIFFUSER FILTER 1
2 000-169-235 ASSEMBLY, ROBERT FLOAT VALVE 1
3 000-015-938 BRACKET, WATER BOX MOUNTING - COATED 1
4 000-052-728 BULKHEAD, 1/2” FPT 1
5 000-052-660 BULKHEAD, 3/8” FPT x 3/8” FPT 1
6 000-033-003 CLAMP, SIZE #4 MINI HOSE 2
7 000-041-005 COVER, 6” ACCESS 1
8 000-052-355 ELBOW, 3/8” NPT x 1/2” HOSE 2
9 000-052-086 ELBOW, 3/8” NPT STREET 1
10 000-068-326 HOSE, 3/8” I.D. CLEAR w/ BRAID SOLUTION 1
11 000-052-754 INSERT, #F1216 (3/4” FPT x 1” BARB) 1
12 000-081-335 LABEL, WATER BOX 1
13 000-052-662 NIPPLE, 3/8” NPT x 1/4” M SAE 1
14 000-094-009 NUT, 1/4”-20UNC NYLOCK 2
15 000-094-113 NUT, 1/4”-20UNC NEOPRENE WELLNUT 4
16 000-094-097 NUT, 1”-14UNS BRASS 3
17 000-097-041 O-RING, 1/2” BULK HEAD 2
18 000-143-314 SCREW, #8 x 1/2” LG. PAN HEAD 6
19 000-143-002 SCREW, 1/4”-20UNC x 1.00” LG. HEX HEAD 4
20 000-143-017 SCREW, 3/8”-16UNC x 0.75” LG. HEX HEAD GRD. 8 4
21 000-157-0801 SWITCH, w/PROTECTOR,
POLYPROPELENE BARREL - NC 1
22 000-159-107 TANK, POLY WATER BOX - MODIFIED 1
23 000-052-156 TEE, 1/4” PLASTIC 1
24 000-052-023 TEE, 3/8” NPT MALE STREET 1
25 000-174-003 WASHER, 1/4” FLAT S/S 2
26 000-174-060 WASHER, 1/4” FLAT RUBBER BACKED 4
27 000-174-057 WASHER, 3/8” LOCK 4
28 000-174-063 WASHER, 1.5” O.D. x 1.073” I.D. x 0.075” THK. 2
29 000-174-032 WASHER, 3/8” FLAT 4
30 000-174-017 WASHER, 1/4” LOCK 4
31 000-174-028 WASHER, 7/8” I.D. x 1.50” O.D. x 0.090” THK. 2
Item Part Number Description Qty
Item Part Number Description Qty
