Hypertherm Powermax 85

COMPONENT REPLACEMENT
6-26 powermax 65/85 Service Manual
4
4
7
7
6
6
3
3
DSP back view
1
4
2
3
DSP front view
Replace the Mylar barrier and power supply cover.
1. Replace the Mylar barrier. Refer to page 6-3 Replace the Mylar barrier.
2. Replace the power supply cover. Refer to page 6-4 Replace the power supply cover.
3. Reconnect the electrical power and the gas supply.
