Hypertherm Powermax 85 Service Manual

Torch SeTup
3-36 powermax 65/85 Service Manual
45A Shielded Air flow rate - slpm/scfh
Stainless Steel
Hot 150 / 310
Cold 210/ 450
Metric
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
mm mm mm % seconds (mm/min) Volts (mm/min) Volts
0.5
1.5 3.8 250
0.0
9000 130 12500 129
1 9000 130 10800 130
1.5 0.1 9000 130 10200 130
2 0.3 6000 132 8660 131
3
0.4
3100 132 4400 132
4 2000 134 2600 134
6 0.5 900 140 1020 139
English
Material
Thickness
Torch-
to-Work
Distance
Initial Pierce
Height
Pierce
Delay Time
Best Quality Settings Production Settings
Cut Speed Voltage Cut Speed Voltage
in in % seconds ipm Volts ipm Volts
26GA
0.06 0.15 250
0.0
350 130 500 129
22GA 350 130 450 129
18GA
0.1
350 130 400 130
16GA 350 130 400 130
14GA 0.2 250 132 360 131
12GA
0.4
140 132 206 131
10GA 100 133 134 134
3/16 in 0.5 52 135 58 135
1/4 in 0.6 30 141 35 140

Hypertherm Powermax 85 Specifications

General

Gas Supply	Clean, dry, oil-free air or nitrogen
Cooling Method	Fan-cooled
Input Voltage	200-600V, 3-phase
Current Output	25-85 A
Duty Cycle	60% @ 85 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Cutting Capacity (Recommended)	1" (25 mm)
Gas Type	Air/Nitrogen
