A
．
INSTALLATION MANUAL
FOR ELECTRICAL PARTS
When JUMP is released,
it works as REAR(=handicap) HIP.
At normal time,
JUMP is connected.
When the sticker is removed, you can verify LED
status.
When there is a
problem check LED
defect.
Floor setting
mode
(FL_SET)
When there is a JUMP, it enters floor ID input mode.
(After completion, release JUMP and turn power OFF -> ON)
Use Up/Down button
to input floor ID.
• Floor setting has the corresponding floor input at ship-out before delivery
• to the site. Floor ID is fixed
• For CPI, floor ID is set with『CP』, and for HPI, floor ID is set with『HP』,
• and delivered to the site.
