3.4 How to Set HIP / HPI Floor ID (For GH5, use DIP SWITCH in the board)
Order
Contents
Note
1
Connect 24VDC power to the CH1 or CH4 of HIP / HPI
Board
2
Connect the UP / DOWN Button to the CH2 or CH2B of
board
3
Jump the FL_SET(=JP3)
4
Input the floors according to the ID data of each floor by
seeing the DOT-MATRIX display
Setting
5
Push the UP or DOWN Button during 5 sec
6
If you can see the alternating display 『OK』 and 『setting
floor』 on the DOT-MATRIX, the floor setting is completed
Completed
7
Release FL_SET(=JP3) jumper
Release setting mode
The floor ID can be set from 1 to 96, the english display after 96 floor is special functions.
Floor ID
Set Floor ID
Note
CP
In case that by using the CAR indicator
HP
In case of using 2 indicator on hall, one thing
have to set as floor ID HP
SV
In case that by using the supervisor indicator
When it Applies
SUPERVISORY option
