1.2 Specifications
1-8
1. Specifications
[Payload by Acceleration]
At low load capacity, the acceleration/deceleration can be increased.
Lead30 Lead20
Horizontal Vertical Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
11 6 6 4 3 3.5 2 2 1.51.5 18 15 10 8 6 6 5 4 4 2
Lead12 Lead6
Horizontal Vertical Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
30 24 20 15 15 11 10 10 8 8 45 30 20 20 ‒ 15 15 15 15 ‒
Lead3
Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
45 30 20 ‒ ‒ 15 14 10 ‒ ‒
Caution
Do not attempt to configure settings for acceleration/deceleration above the specifications.
This may lead to vibration, breakdown, or shortened product life.

IAI ROBO Cylinder RCS4- SA4C Specifications
