1.3 Options
1-32
1. Specifications
Slider Roller Specification (Model Code: SR)
The structure of the slider in the standard type can be changed to the roller structure same as the
one in the cleanroom type.
If it gets chosen to have the slider roller type, the appearance and dimensions of the slider cover
should become the same as the cleanroom type.
Vacuum Joint Attachment Opposite Type (Model Code: VR)
The vacuum joint should be attached on the left of the main unit in the view from the motor end in
standard, which can be changed to the right (opposite) in option.
Double Slider Specification (Model Code: W)
This is an option that adds a free slider that is not connected to the ball screw.
Doubling the slider makes it possible to increase the moment and the overhang load length.
* Refer to" Double Slider (Option) (Page 1-28)" in "1.2 Specifications" for details.
Rear Attachment Plate (Model Code: RP)
It is a bracket (plate) to affix the motor reversed type (SA4R) at the back to a device.
