1.4 Accessories
1-35
1. Specifications
1.4 Accessories
Motor Cable
● The cable length should be 1m at minimum and 20m at maximum.
Order can be make in unit of 1m long.
● An example for model codes is as shown below.
Cable length 1
m → CB-RCC-MA010 (-RB)
Cable length 3
m → CB-RCC-MA030 (-RB)
Cable length 10
m → CB-RCC-MA100 (-RB)
Model code: CB-RCC-MA□□□/ CB-RCC-MA□□□-RB
Controller Side
Actuator Side
Wire Size Color Signal No. Wire SizeColorSignalNo.
Green
Red
White
Black
Red
White
Black
Green
(Crimped)
(16)
(20)
(10)
(
φ
9)
(21)
(18)
(41)
1
1
4
4
(Front View)
(Front View)
Minimum bending radius r = 51mm or more (for movable use)
* It is only robot cable available to use inside the cable track
To Next Page
