1.4 Accessories
1-36
1. Specifications
Encoder Cable
● The cable length should be 1m at minimum and 20m at maximum.
Order can be make in unit of 1m long.
● An example for model codes is as shown below.
Cable length 1
m → CB-X1-PA010
Cable length 3m → CB-X1-PA030
Cable length 10
m → CB-X1-PA100
Model code: CB-X1-PA□□□
Controller Side
Actuator Side
Color
Signal
No.
(
φ
8)
(Front View)
(Front View)
Clamp the shield to the hood.
Ground wire or braided shield wire
L
(41)
(13)
(37)
(14)
(8)
(25)
1
1
13
14
26
Wire Size
AWG26
(Soldered)
AWG26
(Crimped)
Color
SignalNo.
Wire Size
Orange
Orange
Green
Green
Purple
Purple
Gray
Gray
Red
Red
Black
Black
Blue
BlueYellow
Yellow
Drain
Minimum bending radius r = 44mm or more (for movable use)
*Robot cable is standard for this model.
To Next Page
