1.2 Specifications
1-5
1. Specifications
[Payload by Acceleration]
At low load capacity, the acceleration/deceleration can be increased.
Lead 16 Lead 10
Horizontal Vertical Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
10 8 6 6 4 3 3 1.5 1.5 1 14 14 12 10 6 5 5 3 3 2
Lead 5 Lead 2.5
Horizontal Vertical Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
17 17 15 15 ‒ 8 8 6 6 ‒ 20 20 20 ‒ ‒ 12 12 10 ‒ ‒
Caution
Do not attempt to configure settings for acceleration/deceleration above the specifications.
This may lead to vibration, breakdown, or shortened product life.
