[Suction amount guideline]
Double slider specification (option model W)
Model Number Lead [mm]
Suction Amount
Nl/min (L/min)
SA4C
10 60(65)
5 30(32)
2.5 20(22)
SA6C
12 110(119)
6 60(65)
3 35(38)
SA7C
16 100(108)
8 50(54)
4 40(43)
SA8C
10 120(130)
5 50(54)
Notice
● Please perform suction of air from the two vacuum joints located on the sides of the
actuator according to the suction amounts (total amount of the two locations) shown in
the table below.
Also, please manage the joints so that the suction amounts of the two locations are
equivalent.
● Please use the actuator in a state in which all of the base attachment holes on the
bottom of the actuator are covered. When there is a hole that passes through the
actuator, the level of cleanliness decreases.
