Illustrations Of Printer Components
279
Item
No.
Part No.
(Order No.)
Description Notes
1 57G1440 Fan Assembly Air flow is into card cage
2 Ref Screw, w/Lock Washer (3) Two 6-32x1.75 on botton
One 6-32x0.50 on top left
3 14H5281
14H5570
Paper Detector Switch Assy
Paper Detector Switch Assy
Standard
Black Back forms
4 Ref Screw, Thread Forming, 6-32x.375
5 14H5520 Paper Feed Motor Assy Includes items 7 through 9
6 08H7934 Motor Pulley, Platen Open Part of Platen Open Motor
Assy 57G1509 and includes
collar setscrew 6-32x.25
7 Ref Collar Part of item 9
8 Ref Screw, Socket Head, 6-32x.51
9 57G1421 Motor Pulley, Paper Feed
10 Ref Screw, Hex w/Lock Washer (2) 10-32x.50
11 24H8894 Ribbon Guide Kit Includes left and right ribbon
guides
12 14H5154 Platen Open Motor Assembly Includes item 6
13 Ref Washer, Flat #4 (2)
14 Ref Screw, Hex w/Lock Washer (2) 4-40x.38
15 Ref Screw, Hex w/Lock Washer (2) 10-32x.50
16 Ref Shield, Card Cage Fan
17 14H5521 Motor Assembly, Ribbon
18 Ref Screw, Hex w/Lock Washer (2) 6-32x.50
19 Ref Washer, Flat #6 (2)
20 57G1479 Ribbon Hub Kit
21 Ref Screw, w/Lock Washer (2) 6-32x1.25
22 14H5159 Hammer Bank Fan Assembly Air flow is up
23 Ref Boot Cabinet models only
