Chapter 7 Section II: Illustrated Parts Lists
Figure 53. Circuit Breaker
To IEC 320 AC Power
Input (Connector J301,
White Wire)
To Connector P1
(Black Wire)
To IEC 320 AC Power
Input (Connector J301,
Black Wire)
To Connector P1
(White Wire)
$
%
$
%
See inside detail below.
Card cage fan and
power supply board
removed for clarity.
4
5
3
2
White Wire
Black Wire
White Wire
Black Wire
1
