Component Name AIX Location Code
Physical Location
Code Logical Identification
Central Electronics Complex (CEC)
System Board 00-00 P1
Processor Card 1 00-00 P1-C1 Processor 0
Processor Card 2 00-02 P1-C2 Processor 2
Memory Card 00-00 P1-M1
Memory DIMMs on
Memory Card
00-00 P1-M1.1 thru
P1-M1.16
Extents:
0H, 0L, 2H, 2L, 4H,
4L, 6H, 6L, 1H, 1L,
3H, 3L, 5H, 5L, 7H, 7L
Integrated Devices
Diskette Drive 01-D1-00-00 P1-D1
Keyboard 01-K1-00-00 P1/K1-K1
Mouse 01-K1-01-00 P1/O1-O1
Diskette Port 01-D1 P1/D1
Keyboard Port 01-K1-00 P1/K1
Mouse Port 01-K1-01 P1/O1
Serial Port 1 01-S1 P1/S1
Serial Port 2 01-S2 P1/S2
Serial Port 3 01-S3 P1/S3
Parallel Port 01-R1 P1/R1
Ethernet Port 1 10-80 P1/E1
Ethernet Port 2 10-88 P1/E2
Internal SCSI Port 10-60 P1/Z1
External SCSI Port 10-61 P1/Z2
IDE Port 10-58 P1/Q1
Base CD-ROM (IDE)
in bay D03
10-59 P1/Q1–A2
Pluggable Adapters
PCI Host Bridge 1 00-FEE00000 P1
Card in PCI Slot 1 20-58 to 20-5F or
2B-xx
P1-I1
Card in PCI Slot 2 20-60 to 20-67 or
2C-xx
P1-I2
PCI Host Bridge 0 00-FEF00000 P1
Card in PCI Slot 3 10-68 to 10-6F or
1D-xx
P1-I3
Card in PCI Slot 4 10-70 to 10-77 or
1E-xx
P1-I4
Chapter 1. Reference Information
19
