Component Name AIX Location Code
Physical Location
Code Logical Identification
Card in PCI Slot 5 10-78 to 10-7F or
1F-xx
P1-I5
SCSI Devices
SCSI Backplane N/A P2
SCSI Repeater
Backplane
N/A N/A
SCSI Device in bay
D01
10-60-00-0,0 P1/Z1–A0 Internal SCSI Bus ID 0
SCSI Device in bay
D02
10-60-00-1,0 P1/Z1-A1 Internal SCSI Bus ID 1
SCSI Device in bay
D03
10-60-00-2,0 P1/Z1-A2 Internal SCSI Bus ID 2
SAF-TE Controller 10-60-00-9-0 P1/Z1–A9 SCSI Enclosure
Services Controller
Hot-swap DASD bay 1 10-60-00-10,0 P1/Z1-Aa Primary SCSI Bus ID
10
Hot-swap DASD bay 2 10-60-00-11,0 P1/Z1-Ab Primary SCSI Bus ID
11
Hot-swap DASD bay 3 10-60-00-12,0 P1/Z1-Ac Primary SCSI Bus ID
12
Hot-swap DASD bay 4 10-60-00-13,0 P1/Z1-Ad Primary SCSI Bus ID
13
Hot-swap DASD bay 5 10-60-00-14,0 P1/Z1-Ae Primary SCSI Bus ID
14
Hot-swap DASD bay 6 10-60-00-15,0 P1/Z1-Af Primary SCSI Bus ID
15
Fans
Fan 1 F1 Fan
Fan 2 F2 Fan
Fan 3 F3 Fan
Fan 4 F4 Fan
Operator Panel
Operator panel L1
Lightpath
LED panel
L2
Power Supply
Power backplane P3
Power supply 1 P3-V1
Power supply 2 P3-V2
Power supply 3 P3-V3
20 Service Guide
