IBM N Series - N62 X0 Technical Specifications

Chapter 3. Mid-range systems 31
3.3 N62x0 technical specifications
Table 3-1 shows the N62x0 specifications.
Table 3-1 N62x0 specifications
For more information about N series 6000 systems, see this website:
http://www.ibm.com/systems/storage/network/n6000/appliance/index.html
N6220 N6220 (with optional IOXM) N6250 (always with IOXM)
Configuration Single-node Dual-node Single-node Dual-node Single-node Dual-node
Machine type 2858-C15 2658-C25 2858-E15 2858-E25 2858-E16 2858-E26
Gateway feature FC# 9551
Processor type 2.3 GHz Intel (Quad Core)
Number of
Processors
121224
Memory 12 24 12 24 20 40
NV RAM 1.6 GB 3.2 GB 1.6 GB 3.2 GB 2 GB 4 GB
Onboard I/O ports
FC ports (Speed) 2 (4 Gb) 4 (4 Gb) 2 (4 Gb) 4 (4 Gb) 2 (4 Gb) 4 (4 Gb)
Ethernet ports 2 (1 Gb) 4 (1 Gb) 2 (1 Gb) 4 (1 Gb) 2 (1 Gb) 4 (1 Gb)
SAS ports 2 (6 Gb) 4 (6 Gb) 2 (6 Gb) 4 (6 Gb) 2 (6 Gb) 4 (6 Gb)
Storage scalability
Max. FC loops 5 13 13
Max. disk drives 480 480 720
Max. raw
capacity
1920 TB
(with 4 TB disks)
1920 TB
(with 4 TB disks)
2880 TB
(with 4 TB disks)
Max. volumes 500 1000 500 1000 500 1000
Max volume size 60 TB (64-bit) 60 TB (64-bit) 70 TB (64-bit)
I/O scalability
PCIe slots 2 4 6 12 6 12
Max. FC ports102026522652
Max. Enet ports 10 20 26 52 26 52
Max. SAS ports 10 20 26 52 26 52
