48 IBM System Storage N series Hardware Guide
5.2.2 Supported EXN3000 drives
Table 5-1 lists the drives that are supported by EXN3000 at the time of this writing.
Table 5-1 EXN3000 supported drives
5.2.3 Environmental and technical specifications
Table 5-2 shows the environmental and technical specifications.
Table 5-2 EXN3000 environmental specifications
5.3 Expansion unit EXN3200
IBM System Storage EXN3200 Model 306 SATA Expansion Unit is a 4U high-density SATA
enclosure for attachment to PCIe-based N series systems with SAS ports. The EXN3200
ships with 48 disk drives per unit.
The EXN3200 is a disk storage expansion unit for mounting in any industry standard 19-inch
rack. The EXN3200 provides low-cost, high-capacity SAS disk storage for the IBM N series
system storage family.
The EXN3200 must be ordered with a full complement of (48) disks.
EXN3000 RPM Capacity
SAS 15 K 600 GB
600 GB encrypted
SATA 7.2 K 1 TB
2 TB
3 TB
3 TB encrypted
4 TB
SSD N/A 200 GB
EXN3000 Specification
Disk 24
Rack size 4U
Weight Empty: 21.1 lb. (9.6 kg)
Without drives: 53.7 lb. (24.4 kg)
With drives: 110 lb. (49.9 kg)
Power SAS: 300 GB 6.0A, 450 GB 6.3A, 600 GB 5.7A
SATA: 1 TB 4.4A, 2 TB 4.6A, 3 TB 4.6A
SSD: 100 GB 1.6A
Thermal (BTU/hr) SAS: 300 GB 2048, 450 GB 2150, 600 GB 1833
SATA: 1 TB 1495, 2 TB 1561, 3 TB 1555
SSD: 100 GB 557
