Installing or replacing the display panel assembly: 2145-92F
You can replace the display panel assembly in a 2145-92F expansion enclosure.
About this task
This task assumes that the following conditions were met:
• The expansion enclosure was moved out from the rack on the slide rails, as described in “Removing an
expansion enclosure from a rack: 2145-92F ” on page 94
• The top cover was removed, as described in “Removing the top cover: 2145-92F ” on page 56.
• The display panel assembly was removed, as described in “Removing the display panel assembly:
2145-92F ” on page 117.
Procedure
1. Remove the display panel assembly, which is shown in Figure 130 on page 120, from its packaging.
Chapter 4. Installing an optional 5U SAS expansion enclosure 119
