Figure 116. Secondary expander module connectors
5. Place the secondary expander module in a safe location, as shown in Figure 117 on page 108.
Figure 117. Secondary expander module removed from the enclosure
6. If needed, repeat step “2” on page 107 through step “5” on page 108 to remove the other secondary
expander module.
Replace the secondary expansion module
7. To reinstall the secondary expansion module, or replace it with one from FRU stock, follow the
procedure in “Installing or replacing a secondary expander module: 2145-92F ” on page 77.
108
SAN Volume Controller : Model 2145-SV1 Hardware Installation Guide
