Appendix C. SAN Volume Controller physical
installation planning
Before the IBM service representative can set up your environment, you must verify that the prerequisite
conditions for system installation are met.
SAN Volume Controller 2145-SV1 environment requirements
Before the SAN Volume Controller 2145-SV1 is installed, the physical environment must meet certain
requirements. This includes verifying that adequate space is available and that requirements for power
and environmental conditions are met.
Input-voltage requirements
Ensure that your environment meets the voltage requirements that are shown in Table 25 on page 147.
Table 25. Input-voltage requirements
Voltage Frequency
100-127 / 200-240Vac 50 Hz or 60 Hz
Maximum power requirements for each node
Ensure that your environment meets the power requirements as shown in Table 26 on page 147.
The maximum power that is required depends on the node type and the optional features that are
installed.
Table 26. Power consumption
Components Power requirements
SAN Volume Controller 2145-SV1 ~450 W typical, 700 W maximum (200 - 240V ac,
50/60 Hz)
Environment requirements without redundant AC power
Ensure that your environment falls within the following ranges if you are not using redundant AC power.
If you are not using redundant ac power, ensure that your environment falls within the ranges that are
shown in Table 27 on page 147.
Table 27. Physical
specications
Environment Temperature Altitude Relative humidity
Maximum dew
point
Operating in lower
altitudes
5°C to 40°C
(41°F to 104°F)
0 - 950 m
(0 ft to 3,117 ft)
8% to 85% 24°C (75°F)
Operating in higher
altitudes
5°C to 28°C
(41°F to 82°F)
951 m to 3,050 m
(3,118 ft to 10,000
ft)
©
Copyright IBM Corp. 2014, 2018 147
