IBM System x3850 X5 Implementation Guide

Chapter 1. Introduction 7
Also available is a virtualization workload-optimized model of these HX5s. This is a
pre-configured, pre-tested model targeted at large-scale consolidation. Table 1-7 shows the
model.
Table 1-7 Workload-optimized models of the HX5
Model 7872-68x is a virtualization-optimized model and includes the following features in
addition to standard HX5 and MAX5 features:
򐂰 Forty DIMM sockets, all containing 4 GB memory DIMMs for a total of 160 GB of available
memory.
򐂰 VMware ESXi 4.1 on a USB memory key is installed internally in the server. See 5.15,
“Integrated virtualization” on page 214 for details.
򐂰 Emulex Virtual Fabric Adapter Expansion Card (CFFh).
1.3 Positioning
Table 1-8 gives an overview of the features of the systems that are described in this book.
Table 1-8 Maximum configurations for the eX5 systems
Model Intel Xeon
model and
cores/max
Clock
speed
TDP HX5 max
memory
speed
a
a. Memory speed of the HX5 is dependent on the processor installed; however, the memory speed of the MAX5 is
up to 1066 MHz irrespective of the processor installed in the attached HX5.
MAX5 Scalable
to four
socket
10GbE
card
b
b. Emulex Virtual Fabric Adapter Expansion Card (CFFh).
Standard
memory
(max 320 GB)
c
c. HX5 has 16 DIMM sockets and can hold 128 GB using 8 GB memory DIMMs. MAX5 has 24 DIMM sockets and
can hold 192 GB using 8 GB memory DIMMs. A 1-node HX5 + MAX5 supports 320 GB total using 8 GB DIMMs.
Virtualization workload-optimized models (includes VMware ESXi 4.1 on a USB memory key)
7872-68x 2x E6540 6C/2 2.00 GHz 105 W 978 MHz Std No Std
160 GB
HX5: 16x 4GB
MAX5: 24x 4GB
Maximum configurations x3850 X5/x3950 X5 x3690 X5 HX5
Processors 1-node 4 2 2
2-node 8 Not available 4
Memory 1-node 1024 GB (64 DIMMs)
a
512 GB (32 DIMMs)
b
128 GB (16 DIMMs)
1-node with MAX5 1536 GB (96 DIMMs)
a
1024 GB (64 DIMMs)
b
320 GB (40 DIMMs)
2-node 2048 GB (128 DIMMs
a
Not available 256 GB (32 DIMMs)
Disk drives
(non-SSD)
c
1-node 8 16 Not available
2-node 16 Not available Not available
SSDs 1-node 16 24 2
2-node 32 Not available 4
Standard 1 Gb
Ethernet interfaces
1-node 2
d
22
2-node 4 Not available 4

IBM System x3850 X5 Specifications

General

Processor Cores	Up to 10 cores per processor
Chipset	Intel 7500
Hard Drive Interface	SAS/SATA
Processor	Intel Xeon E7-4800 series, Intel Xeon E7-8800 series
Memory Slots	64 DIMM slots
Storage	Up to 16 x 2.5" hot-swap SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 5, 6, 10
Network Interface	Integrated Gigabit Ethernet
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Form Factor	4U Rack
