IBM System x3850 X5 Implementation Guide

524 IBM eX5 Implementation Guide
Sequence Number: 4
Media Error Count: 0
Other Error Count: 0
Predictive Failure Count: 0
Last Predictive Failure Event Seq Number: 0
PD Type: SAS
Raw Size: 136.731 GB [0x11176d60 Sectors]
Non Coerced Size: 136.231 GB [0x11076d60 Sectors]
Coerced Size: 135.972 GB [0x10ff2000 Sectors]
Firmware state: Unconfigured(good), Spun Up
SAS Address(0): 0x5000c50016f81501
SAS Address(1): 0x0
Connected Port Number: 1(path0)
Inquiry Data: IBM-ESXSST9146803SS B53B3SD1GZCW0825B53B
IBM FRU/CRU: 42D0422
FDE Capable: Not Capable
FDE Enable: Disable
Secured: Unsecured
Locked: Unlocked
Foreign State: None
Device Speed: 6.0Gb/s
Link Speed: 6.0Gb/s
Media Type: Hard Disk Device
Drive: Not Certified
Enclosure Device ID: 252
Slot Number: 2
Device Id: 16
Sequence Number: 3
Media Error Count: 0
Other Error Count: 0
Predictive Failure Count: 0
Last Predictive Failure Event Seq Number: 0
PD Type: SAS
Raw Size: 136.731 GB [0x11176d60 Sectors]
Non Coerced Size: 136.231 GB [0x11076d60 Sectors]
Coerced Size: 135.972 GB [0x10ff2000 Sectors]
Firmware state: Unconfigured(good), Spun Up
SAS Address(0): 0x5000c5001cf9c455
SAS Address(1): 0x0
Connected Port Number: 0(path0)
Inquiry Data: IBM-ESXSST9146803SS B53B3SD2FM090825B53B
IBM FRU/CRU: 42D0422
FDE Capable: Not Capable
FDE Enable: Disable
Secured: Unsecured
Locked: Unlocked
Foreign State: None
Device Speed: 6.0Gb/s
Link Speed: 6.0Gb/s
Media Type: Hard Disk Device
Drive: Not Certified
2. Now we can create the virtual drive. In our example, we issue the following command to
create a RAID-1:
MegaCli -CfgLDAdd -R1[252:1,252:2] -a0
Example 9-16 on page 525 shows the resulting output.
