Icom IC-705 - MENU Screen; Multi-Function Menus; Quick Menu

SSB SSB-D CW RTTY
RF POWER*
2
RF POWER*
2
RF POWER*
2
RF POWER*
2
MIC GAIN*
2
MIC GAIN*
2
KEY SPEED*
2
TPF*
1
COMP*
1
*
2
CW PITCH*
2
MONITOR*
1
*
2
MONITOR*
1
*
2
MONITOR*
1
*
2
AM FM/WFM DV NB
RF POWER*
2
RF POWER*
2
RF POWER*
2
LEVEL*
2
MIC GAIN*
2
MIC GAIN*
2
MIC GAIN*
2
DEPTH*
2
WIDTH*
2
MONITOR*
1
*
2
MONITOR*
1
*
2
MONITOR*
1
*
2
NR NOTCH VOX BK-IN
LEVEL*
2
POSITION*
2
GAIN*
2
DELAY*
2
WIDTH*
1
ANTI VOX*
2
DELAY*
2
VOICE DELAY*
1
2-7
BASIC MANUAL
2
PANEL DESCRIPTION
Touch screen display
DMENU screen
z Push to open the MENU screen in the
selected mode.
LTo close the MENU screen, push .
LTouching [1] or [2] at the bottom of the screen
selects MENU screen 1 or 2.
DQUICK MENU
z Push to open the QUICK MENU screen.
DMulti-function menus
z Open the Multi-function menu by pushing
(Multi-function control).
z Open special menus by holding down
or
for 1 second.
z While the Multi-function menu is open, touch
the desired item and rotate
to set the
desired value.
Multi-function menu items
*
1
Touch the edge to turn the function ON or OFF, or
to adjust the selected item.
*
2
Touch the item for 1 second to adjust by rotating
, even when the Multi-function menu is
closed.
Touch to turn
ON or OFF.
