8-13
BASIC MANUAL
8
SET MODE
Connectors
»
SET > Connectors
SP Jack Function (Default: Speaker)
Selects the audio output from the [SP] jack.
• Speaker: The audio is output from only
the Left channel through the
amplifier for a speaker.
• Phone: The audio is output from only
the Left channel through the
amplifier for a headphone.
• Phone (L+R):
The audio is output from the
Right and Left channels through
the amplifier for a headphone.
Phones Level (Default: 0)
Sets the audio output level ratio of the
headphone and internal speaker between -15
and +15.
»
SET > Connectors > USB AF/IF Output
Output Select (Default: AF)
Selects the signal output from the [microUSB]
port.
• AF: An AF signal is output.
• IF: A 12 kHz IF signal is output.
AF Output Level (Default: 50%)
Sets the AF output level of the [microUSB] port,
when “Output Select” of USB is set to “AF.”
AF SQL (Default: OFF (Open))
Selects whether or not to output the audio from
the [microUSB] port, depending on the squelch
state, when “Output Select” of USB is set to “AF.”
• OFF (Open): The squelch is always open,
regardless of the transceiver’s
squelch level.
• ON: The squelch opens and closes,
depending on the transceiver’s
squelch level.
AF Beep/Speech...Output (Default: OFF)
Sets the Beep and Speech audio output setting
of the [microUSB] port, when “Output Select” of
USB is set to “AF.”
• OFF: The beep and speech audio are not
output.
• ON: The beep and speech audio are output.
IF Output Level (Default: 50%)
Sets the IF output level of the [microUSB] port,
when “Output Select” of USB is set to “IF.”
»
SET > Connectors > WLAN AF/IF Output
Output Select (Default: AF)
Selects the signal output to the network.
• AF: An AF signal is output.
• IF: A 12 kHz IF signal is output.
AF SQL (Default: ON)
Selects whether or not to output the audio to the
network, depending on the squelch state, when
“Output Select” of WLAN is set to “AF.”
• OFF (Open): The squelch is always open,
regardless of the transceiver’s
squelch level.
• ON: The squelch opens and closes,
depending on the transceiver’s
squelch level.
»
SET > Connectors > MOD Input
USB MOD Level (Default: 50%)
WLAN MOD Level (Default: 50%)
Sets the modulation input level of each interface.
DATA OFF MOD (Default: MIC,USB)
DATA MOD (Default: USB)
In the SSB, AM, or FM mode, selects the
connector(s) to input the modulation signal
when the Data mode is OFF, or ON.
»
SET > Connectors > SEND Output
HF (Default: ON)
50M (Default: ON)
144M (Default: ON)
430M (Default: ON)
Selects whether or not to switch the SEND
terminal output level of the [SEND/ALC] jack to
the Low level when transmitting.
• OFF: Does not switch to Low level.
• ON: Switches to Low level.
