8-14
BASIC MANUAL
SET MODE
8
8
»
SET > Connectors > USB SEND/Keying
TIP: This is the setting for the terminal used
for data communication when you operate the
transceiver using software on a PC.
When you connect the transceiver to the PC
with a USB cable, 2 COM ports are recognized
on the PC.
To confirm USB (A)/USB (B), open the COM
port properties, and confirm the “Value” on the
“Details” tab.
USB SEND (Default: OFF)
Sets the USB terminal of the transceiver to
receive the SEND signal from the software
on the PC. Select the same terminal as the
terminal set by the software.
LYou cannot select the terminal which is already
selected in the “USB Keying (CW)” or “USB
Keying (RTTY)” item.
USB Keying (CW) (Default: OFF)
Sets the USB terminal of the transceiver to
receive the CW Keying signal from the software
on the PC. Select the same terminal as the
terminal set by the software.
LYou cannot select the terminal which is already
selected in the “USB SEND” or “USB Keying
(RTTY)” item.
USB Keying (RTTY) (Default: OFF)
Sets the USB terminal of the transceiver to
receive the RTTY Keying signal from the
software on the PC. Select the same terminal
as the terminal set by the software.
LYou cannot select the terminal which is already
selected in the “USB SEND” or “USB Keying
(CW)” item.
»
SET > Connectors > External Keypad
VOICE (Default: OFF)
KEYER (Default: OFF)
RTTY (Default: OFF)
Enables each memory (voice, keyer, RTTY)
transmission using an external keypad.
»
SET > Connectors > CI-V
CI-V Address (Default: A4)
Sets the CI-V address in hexadecimal code.
L“A4” is the default address of the IC-705.
CI-V Transceive (Default: ON)
Turns the Transceive function ON or OFF.
• OFF: The status is not output.
• ON: The status is output. When you change
a setting on the transceiver, the same
change is automatically set on other
connected transceivers or receivers,
and vice versa.
CI-V USB Echo Back (Default: OFF)
Turns the Data Echo Back function ON or OFF,
when remotely controlling the IC-705 through
the [microUSB] CI-V port.
»
SET > Connectors > USB (B) Function
USB (B) Function (Default: OFF)
The transceiver has 2 virtual COM ports, A and
B. In this item, sets the function to be assigned
to USB (B).
LUSB (A) is used for programming, or CI-V
operation.
LWhen connecting to a USB port on your PC that is
installed the USB driver, USB (A) and USB (B) are
named as “IC-705 Serial Port A (CI-V)” and “IC-705
Serial Port B.”
• OFF: Does not assign the function
to USB (B).
• RTTY Decode: Outputs the decoded data of
the RTTY signal.
• DV Data: Inputs or outputs low speed
data for the DV mode.
• Weather:
Inputs the weather data entries.
GPS Out (Default: OFF)
Selects whether or not to output the position
data to USB (B).
• OFF: Does not output the position
data to USB (B).
•
USB (B).
LIt is valid when “USB (B) Function” is set to “OFF”
or “DV Data.”
»
SET > Connectors
MIC Jack 8V Output (Default: OFF)
Selects whether or not to output 8 V from the
[MIC] jack.
• OFF: Output 3.3 V from the [MIC] jack.
• ON: Output 8 V from the [MIC] jack.
