6-1
BASIC MANUAL
6
microSD CARD
The microSD cards and microSDHC cards are user
supplied.
TIP: Icom recommends that you save the
transceiver’s factory default data for backup.
About the microSD cards
You can use a microSD card of up to 2 GB, or a
microSDHC of up to 32 GB. Icom has checked
the compatibility of the following cards.
(As of July 2020)
Brand Type Memory size
SanDisk
®
microSD 2 GB
microSDHC 4/8/16/32 GB
L The above list does not guarantee the card’s performance.
L Throughout the rest of this document, the microSD
cards and microSDHC cards are simply called the
microSD card or the card.
NOTE:
• Before using the microSD card, thoroughly read
their instructions.
• If any of the following occur, the card’s data may be
corrupted or deleted.
- You remove the card from the transceiver while it
is still accessing the card.
- A power failure occurs, or the power cable is
disconnected, while accessing the card.
- You drop, impact, or vibrate the card.
• Do not touch the contacts of the card.
• The transceiver may take a longer time to recognize
a high capacity card.
• The card has a certain lifetime, so data reading or
writing may not be possible after using it for a long
period of time. In that case, use a new one.
We recommend you to make a backup of the data
onto another device.
• Icom will not be responsible for any damage caused
by data corruption on a card.
Saving data
You can save the following data onto the card.
• The transceiver’s settings
• Communication/receive log and contents
• Automatic answering voice audio in the DV mode
• Voice audio for the Voice TX function
• RTTY decode log
• Captured screens
• Memory channel contents
• Your (UR) call sign memory
• Repeater List
• GPS memory
• Position data from the GPS receiver
• Pictures for the Share Pictures function
• Transmitted and received log of Share Picture
• Pictures for the Opening Picture setting
Inserting
Insert the microSD card
as shown to the left.
L Insert the microSD card
into the slot until it locks
in place, and makes a
‘click’ sound.
L Be sure to check the
card orientation before
inserting.
NOTE:
Before using a microSD card for the first time,
format it in the transceiver.
• Formatting a card erases all its data. Before
formatting any used card, back up its data onto
another device.
• After inserting or formatting, a special folder
on the card that you need for operations like
updating the firmware is created on the card.
IMPORTANT: Even if you have formatted a microSD
card, some data may remain in the card. When you
dispose the card, be sure to physically destroy it to
avoid unauthorized access to any data that remains.
Formatting
Before using a microSD card, format it to be used
with the transceiver by doing the following steps.
1. Open the SD CARD screen.
»
SET > SD Card
2. Touch “Format.”
3. Touch [YES] to start formatting.
• After formatting, returns to the SD CARD screen.
LTo cancel formatting, touch [NO].
4. To close the SD CARD screen, push
several times.
Cut corner side
