4
SCOPE OPERATION
4-6
Spectrum scope screen (Continue)
D Scope set screen (Continued)
Waveform Type (Default: Fill)
Select the outline waveform display for the FFT scope
screen.
• Fill: The waveform is drawn only in color.
•
Fill + Line: The waveform is drawn in color with an outline.
Waveform Color (Current)
(Default: (R) 172 (G) 191 (B) 191)
Set the waveform color for the currently received signals.
L Touch and select the color scale, and then rotate .
Waveform Color (Line) (Default: (R) 56 (G) 24 (B) 0)
Set the waveform outline color for the currently
received signals.
L Touch and select the color scale, and then rotate .
Waveform Color (Max Hold)
(Default: (R) 45 (G) 86 (B) 115)
Set the waveform color for the received signals
maximum level.
L Touch and select the color scale, and then rotate .
Marker Color (RX) (Default: (R) 0 (G) 180 (B) 0)
Set the pointer color for the RX Marker in the Fixed mode.
L Touch and select the color scale, and then rotate .
Marker Color (Peak) (Default: (R) 238 (G) 17 (B) 34)
Set the pointer color for the Peak Marker.
L Touch and select the color scale, and then rotate .
Waterfall Display (Default: ON)
Turn the Water fall display ON or OFF for the normal
scope or Mini scope screens.
• OFF: Turns OFF the Waterfall display.
• ON: Turns ON the Waterfall display.
L In the Expanded scope screen, the Waterfall is always
displayed.
Waterfall Speed (Default: Mid)
Select the Waterfall speed.
• Slow: Sets the waterfall speed to Slow.
• Mid: Sets the waterfall speed to Mid.
• Fast: Sets the waterfall speed to Fast.
Waterfall Size (Expand Screen) (Default: Mid)
Select the Waterfall height for the Expand scope screen.
• Small: The same height with the Normal scope
screen, only the FFT scope expands.
• Mid: The Waterfall height expands at the same
ratio with the FFT scope.
• Large: Only the Waterfall height expands.
Waterfall Peak Color Level (Default: Grid 8)
Select the signal level that the Waterfall displays
a peak color. Higher signal levels are Red, Yellow,
Green, Light-blue, Blue and Black, in that order.
• Option: Grid 1 ~ Grid 8
Waterfall Marker Auto-hide (Default: ON)
Set the Waterfall Marker Auto-hide function to ON or OFF.
• OFF: The marker in the Waterfall zone stays ON.
• ON: The marker in the Waterfall zone is hidden
2 seconds after you have stopped it in place.
Peak Excursion (Default: 6dB)
Set the difference of amplitude between the peak
signal and nearby signals that determines what is
considered a "peak."
• Settable range: 0 dB ~ +60 dB
Peak Threshold (Default: –70dB)
Set the threshold level for the Peak signal detection.
• Settable range: –80 dB ~ 0 dB
Peak Search Target Type (Default: Current)
Select the spectrum waveform type to search.
• Current: Search signals in the current
waveform.
• Max Hold: Search signals in the peak hold
waveform.
