9
SCANS
9-7
Memory scan and Select Memory scan
Memory scan
99ch
00ch
01ch 02ch 03ch
04ch
05ch06ch50ch98ch
Repeatedly scans all entered Memory channels
except Program Scan Edges.
LYou can scan memory channels only in the desired group.
LBlank channels are skipped.
L If two or more Memory channels are not entered, the
Memory scan does not start.
Select Memory scan
99ch
1
00ch
1
01ch
2
02ch
1
03ch
1
04ch
1
05ch
1
06ch
2
50ch
3
98ch
1
Repeatedly scans all or one of 9 Select Memory
channels (★1 ~ ★9) that are assigned as Select
Memory channels
.
L You can scan Select Memory channels only in the
desired group.
L If two or more Memory channels are not assigned as a
Select Memory channels, the Select Memory scan does
not start.
D Memory scan operation
1. Open the SCAN screen.
» SCAN
2. Touch [TYPE/SET].
3. Touch [MEMO].
4. Touch [SELECT] to select the item, then rotate
to change the setting.
• Set the channel group* and edge channels.
* If you do not specify the group, set [Group] to "ALL."
5. Touch [SELECT] several times to exit the edit
mode, then touch [START].
• The Memory scan starts.
LTo cancel the scan, touch [STOP] or push .
6. To close the SCAN screen, push
.
D Select Memory scan operation
1. Open the SCAN screen.
» SCAN
2. Touch [TYPE/SET].
3. Touch [SEL].
4. Touch [SELECT] to select the item, then rotate
to change the setting.
• Set the channel group*, edge channels and the Select
Scan number (Sel No.).
* If you do not specify the group, set [Group] to "ALL."
5. Touch [SELECT] several times to exit the edit
mode, then touch [START] to start the Select
Memory scan.
LTo cancel the scan, touch [STOP] or push .
6. To close the SCAN screen, push
.
SCAN screen
SCAN screen
Blinks
Deactivated
during a Memory
scan
Blinks
Deactivated
during a Memory
scan
(Example) Group: ALL (Each channel is in the different group.)
Blank channels are skipped
Only " " tagged channels are scanned.
"
" indicates the Selected (Tagged) Channel.
(Example) Group: ALL (Each channel is in the different group.)
