8
MEMORY OPERATION
8-2
z Rotate or to select the desired
memory channel.
L Only the Memory channels that have contents are
displayed.
A single memory channel stores the frequency,
receive mode and IF lter width besides the following
items.
• Tuning step • DUP direction
• P.AMP ON/OFF • TSQL/DTCS setting
• ATT setting • DIGITAL Squelch settings
• Antenna setting • Memory name
• IP+ ON/OFF • SKIP Setting
• DUP mode • SELECT Setting
1. Set the frequency and receive mode and so on.
2. Push .
3. Touch to select the desired memory write option.
[Write to a New Channel]:
• The contents such as frequency and operating mode are
written to a blank channel in the selected group.
[Write to the Selected Channel]:
• The selected channel is overwritten.
[Select the Channel and Write]:
• The channel is written to the channel selected on the CH
SELECT screen.
Selecting a memory channel
Writing a memory channel
(Example: Memory channel 04)
Memory mode
Group number Channel number
D Selecting with
1. Push
to select the Memory mode.
2.
Rotate to select the desired memory channel.
D Selecting with
1. Push
to select the Memory mode.
2. Push .
• LED on the key lights.
3. Rotate to select a memory channel.
D Selecting using the keypad
1. Touch the memory channel number.
• The VFO/MEMORY screen is displayed.
2. Push or to select the group.
3. Touch [CH-INP].
4. Touch the numeric keys to enter the desired
memory channel number.
5. Touch [ENT] to set the entered memory channel.
6. Push to close the VFO/MEMORY screen.
Memory write options
Number of
remaining blank
channels
Channel
number
Memory
contents
Group
Memory name
(if entered)
Insert a new channel without overwriting
the selected channel.
CH SELECT screen example
InformationL : Selecting a memory channel in a different group
You can select the desired Memory channel stored in all memory channel groups.
1. Push , and touch [Channel Select Group Range].
2. Touch [All Groups].
3. Rotate to continuously select a memory channel
in all memory channel groups.
To Next Page
