11
SET MODE
11-7
Connectors (Continued)
CI-V > CI-V USB (Rear) Port
(Default: Unlink from [REMOTE])
Selects the internal connection type between the [USB]
port on the rear panel and the [REMOTE] CI-V port.
• Link to [REMOTE]:
The [USB] port on the rear panel and the
[REMOTE] CI-V port are internally connected.
• Unlink from [REMOTE]:
The [USB] port on the rear panel and [REMOTE]
CI-V port are not internally connected.
Each port functions independently.
(duplex communication can be made.)
CI-V > CI-V USB (Rear) Baud Rate (Default: Auto)
Selects the CI-V data transfer rate (bps) for [USB] on
the rear panel.
• Options:
4800, 9600, 19200, 38400, 57600, 115200 or Auto
L When “Auto” is selected, the baud rate is automatically set
according to the data rate of the connected controller.
L This setting is valid only when the “CI-V USB Port” item is
set to “Unlink from [REMOTE].”
CI-V >
CI-V USB (Rear) Echo Back (Default: OFF)
Turns the Data Echo Back function ON or OFF, when
remotely controlling through the [USB] CI-V port.
• OFF: Turns OFF the function.
• ON: Turns ON the function.
L This setting is .valid only when the “CI-V USB Port” item is
set to “Unlink from [REMOTE].”
External Meter Output (Default: Signal)
Selects the signal output from [METER].
• Signal: Signal strength.
• Signal+SQL: Signal strength and squelch level.
External Meter Level (Default: 50%)
Sets the voltage level output from [METER].
• Range: 0 ~ 100%
L 8 V DC is output at full scale (50%). (into a 10 kΩ load)
REF IN/OUT (Default: OFF)
Selects the receiver’s reference frequency signal source.
• IN: Uses an external reference signal.
NOTE: SELECT “OFF” or “OUT” if you are
not use a reliable external signal source.
When the input signal source level is too low,
or the frequency precision is not high, the fre-
quency readout blinks and the receiver does
not function correctly.
• OFF: Does not input/output the reference signal.
• OUT: Outputs the internal reference signal.
Network
DHCP (Valid after Restart) (Default: ON)
Turns the DHCP function ON or OFF.
• OFF: Uses the static IP address.
• ON: Uses the DHCP function.
If a DHCP server is in your network environ-
ment, the IP address is automatically obtained.
LThis setting takes effect after restart.
IP Address (Valid after Restart)
(Default: 192.168. 0. 10)
Sets the static IP address.
L This setting is valid when “OFF” is selected the [DHCP
(Valid after Restart)] item.
LThis setting takes effect after restart.
Subnet Mask (Valid after Restart)
(Default: 255.255.255.0 (24bit))
Sets the subnet mask to connect to your PC or LAN
(Local Area Network), through the Ethernet. Rotate
to set.
• Range: 128.0.0.0 (1 bit) ~ 255.255.255.252 (30 bit)
LThis setting takes effect after restart.
Default Gateway (Valid after Restart)
(Default: . . . )
When you remotely control the IC-R8600 using the
optional RS-R8600 (future product), a default gateway
setting is required.
L This setting is valid when “OFF” is selected the [DHCP
(Valid after Restart)] item.
LThis setting takes effect after restart.
Primary DNS Server (Valid after Restart)
(Default: . . . )
If there are two DNS server addresses, enter the pri-
mary DNS server address.
LThis setting takes effect after restart.
2nd DNS Server (Valid after Restart)
(Default: . . . )
If there are two DNS server addresses, enter the sec-
ondary DNS server address.
LThis setting takes effect after restart.
» SET > Network
To Next Page
