Icom IC-T70A User Manual

New2001
33
6
MEMORY/CALL CHANNELS
New2001
■ Memory bank selection
q Push [V/M/C] to select the memory mode.
w Push [BAND] to enter the bank selection mode.
e Rotate [DIAL] to select a desired bank (A to Z), then push
[BAND].
•Onlyprogrammedbanksaredisplayed.
•Alsoregularmemorychannelcanbeselected.
[DIAL]
Push
Rotate
Bank channel is displayed.
Regular memory
channel
is displayed.
Push
r Rotate [DIAL] to select the bank channel.
•Onlyprogrammedchannelsaredisplayed.
[DIAL]
Bank channel is selected.

Icom IC-T70A Specifications

General

Operating frequency	144 – 148, 440 – 450 MHz
Display type	LCD
Backlight display	Yes
Antenna connector type	FA-S270C
Number of antenna connectors	1
Battery type	BP-265
Product color	Black
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30 mm
Width	58 mm
Height	111 mm
Weight	380 g
