Icom IC-T70A - Starting Full, Band, and Programmed Scans

■ Full/band/programmed scan
q Push [V/M/C] to select the VFO mode.
•Push[BAND] to select a desired frequency band.
w Set the squelch level.
e Push and hold [SCAN](H/M/L) for 1 sec. to enter the scan
type selection mode.
r Rotate [DIAL] to select a desired scanning type.
•Select“ALL”forfullscan,“bAnd”forbandscan,“P-LInkx”for
programmed link scan (x= 0 to 9), “PROGxx” for programmed
scan (xx= 0 to 24; only programmed scan edge numbers are
displayed), “dUP” (appears only when duplex operation is set)
for a duplex scan.
[DIAL]
Full scan
Band scan
Duplex scan
Programmed link scan
Push and hold
for 1 sec.
Programmed scan
Rotate
Selectable from “0” to “9.”
See page 57 for details
of the programming.
Selectable from “0” to “24,”
if programmed. (p. 43)
t Push [SCAN](H/M/L) to start the scan.
•Thescanpauseswhenasignalisreceived.
•Rotate[DIAL] to change the scanning direction. This also re-
sumes scanning.
•Push[V/M/C] to stop the scan.
•Push[BAND] to change the band during band scan, or change
the scan edge during programmed scan/program link scan.
•While continuing to push [SCAN](H/M/L) in step e, rotate
[DIAL] to select a desired scanning type, then release the key
also starts the scan.
During full/band scan During programmed scan
The scan link name or scan name can be displayed instead
of “P-LInk x” for program link scan (x= 0 to 9), “PROGxx” for
programmed scan (xx= 0 to 24) when scan link name or scan
name is programmed and set to ON in the Initial set mode.
Scan link name or scan name is not displayed during scan.
New2001
42
