4: B ASIC I NSTRUCTIONS
TMLO, TIMO, TMHO, and TMSO (Off-Delay Timer)
Four types of on-delay off-delay timers are available; 1-s off-delay timer TMLO, 100-ms off-delay timer TIMO, 10-ms off-delay
timer TMHO, and 1-ms off-delay timer TMSO. A total of 2,000 on- and off-delay timers can be programmed in a user program.
Each timer must be allocated to a unique number T0 through T1999.
For details about device ranges, see "Device Addresses" on page 2-1.
To indirectly specify the value, specify it with a data register number, and specify the value of the data register in the range of 0 to 65,535.
TMLO (1-s Off-delay Timer)
TIMO (100-ms Off-delay Timer)
TMHO (10-ms Off-delay Timer)
TMSO (1-ms Off-delay Timer)
Timer Device Address Range Increments Preset Value
TMLO (1-s off-delay timer) T0 to T1999 0 to 65,535 s 1 s Constant: 0 to 65,535
TIMO (100-ms off-delay timer) T0 to T1999 0 to 6,553.5 s 100 ms
Data registers: D0 to D7999
D10000 to D61999
TMHO (10-ms off-delay timer) T0 to T1999 0 to 655.35 s 10 ms
TMSO (1-ms off-delay timer) T0 to T1999 0 to 65.535 s 1 ms
I1
I0
T0
Ladder Diagram (TMLO)
TMLO
4
T0
I0
ON
OFF
T0
ON
OFF
I1
ON
OFF
Q0
ON
OFF
Timing Chart
4 s
Q0
LOD
TMLO
LOD
AND
OUT
I0
T0
4
I1
T0
Q0
Instruction Data
Program List
I1
I0
T1
Ladder Diagram (TIMO)
TIMO
20
T1
I0
ON
OFF
T1
ON
OFF
I1
ON
OFF
Q1
ON
OFF
Timing Chart
Q1
2 s
LOD
TIMO
LOD
AND
OUT
I0
T1
20
I1
T1
Q1
Instruction Data
Program List
I1
I0
T2
Ladder Diagram (TMHO)
TMHO
100
T2
I0
ON
OFF
T2
ON
OFF
I1
ON
OFF
Q2
ON
OFF
Timing Chart
1 s
Q2
LOD
TMHO
LOD
AND
OUT
I0
T2
100
I1
T2
Q2
Instruction Data
Program List
I1
I0
T3
Ladder Diagram (TMSO)
TMSO
500
T3
I0
ON
OFF
T3
ON
OFF
I1
ON
OFF
Q3
ON
OFF
Timing Chart
0.5 s
Q3
LOD
TMSO
LOD
AND
OUT
I0
T3
500
I1
T3
Q3
Instruction Data
Program List
