IDEC MICROSmart FC6A Series Ladder Programming Manual

FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726 4-3
4: B ASIC I NSTRUCTIONS
Examples: LOD (Load), OUT (Output), and NOT
SET and RST (Reset)
The SET and RST (reset) instructions are used to set (on) or reset (off) outputs, internal relays, and shift register bits. The same
output can be set and reset many times within a program. SET and RST instructions operate in every scan while the input is on.
Valid Devices
The valid device range depends on the FC6A Series MICROSmart type. For details, see "Device Addresses" on page 2-1.
Specify the bit by inserting a "." between the data register number and the bit position.
Note: For restrictions on ladder programming of SET and RST instructions, see "Restriction on Ladder Programming" on page 4-33.
Ladder Diagram
I0
I0
ON
OFF
I1
ON
OFF
Q0
ON
OFF
Q1
ON
OFF
Timing Chart
Q0
Q1I1
LOD
OUT
LOD
OUTN
I0
Q0
I1
Q1
Instruction Data
Program List
Ladder Diagram
M2
Ladder Diagram
Q0
Ladder Diagram
T0
Ladder Diagram
C1
Q0
Q10
Q1
Q2
LOD
OUT
M2
Q0
Instruction Data
LODN
OUT
Q0
Q1
Instruction Data
LOD
OUTN
T0
Q2
Instruction Data
LODN
OUT
C1
Q10
Instruction Data
Program List
Program List
Program List
Program List
Ladder Diagram
I0
I1
I0
ON
OFF
I1
ON
OFF
Q0
ON
OFF
Timing Chart
Q0
S
Q0
R
LOD
SET
LOD
RST
I0
Q0
I1
Q0
Instruction Data
Program List
Instruction I Q M T C R D P
SET
RST
—
0-17
30-10597
0-7997
10000-21247
— — 0-225
0.0-7999.15
10000.15-61999.15
—
