11: W

EEK

ROGRAMMER

NSTRUCTIONS

11-12 FC6A S

ERIES

MICROS

MART

ADDER

ROGRAMMING

ANUAL

FC9Y-B1726

Examples: WEEK

[To turn on output Q0 Monday to Friday each week from 8:30 to 17:15]

Parameter tab

Configure the tab as shown above and set D1 to Q0.

[To turn on output Q0 Tuesday, Wednesday, and Saturday each week from 20:30 to 1:15 the next day]

Parameter tab

Configure the tab as shown above and set D1 to Q0.

S2WEEK S1 S3

M8125

S2WEEK S1 S3

M8125
